DMS-500 NETWORK AUDIO PLAYER demo floor model

The DMS-500Roon ReadyNetwork Audio Player is a groundbreaking design that not only meets today’s digital streaming and file playback demands, considering the wide range of file formats and resolutions, but also looks to the future as well. It’s hard to call something future proof, but the DMS-500 is as close as it gets. The DMS-500 is fullyMQA Certified, but unlike any other MQA product to date, the DMS-500 will playback any MQA sample rate up to 16x. This means despite the original sample rate of the MQA file, the MQA decoder will extrapolate the file to either a 705.6 or 768 kHz sampling rate for stunning realism and studio quality sound.  For non-MQA files, the DMS-500 can stream or playback native PCM files up to 32 bit 384 kHz (.WAV files up to 768 kHz), plus DSD 64, 128, 256, and 512. Connecting the DMS-500 to your wired or wireless home network opens up a new world of musical enjoyment like never before. Easily stream any files from any MAC or PC computer(s), NAS drives, and Internet Music Services like Spotify, TIDAL, and vTuner. The DMS-500 will transform your digital files effortlessly into beautiful analog rich music at a level you’ve come to expect from Cary Audio’s long history of renowned digital products and coveted analog circuitry. Using our proprietary TruBit™ PCM and DSD technology you can actually convert PCM to DSD 64, 128, 256, or upsample in PCM to one of 6 available rates up to 768 kHz at your choosin

Master Clock JitterBelow measurable levelsDigital Sampling Rates (Fs) 44.1 kHz to 768 kHzDigital Filter32-Bit 8x Oversampling Digital FilterDigital/Analog Converters2 – 2 channel AK4490EQ for working on true balanced outputBLUETOOTHQualcomm aptX® lossless fi™ Bluetooth v 4.0 with aptX® low latency audio decoderAnalog Filter3rd Order BesselAnalog OutputsBalanced XLR, Single – Ended RCADigital OutputsCoaxial, Toslink operating at Sample Frequency (Fs) from 44.1 kHz to 192 kHz, 16 bit to 24 bitDigital InputsUSB x 3, SD Card x 1BLUETOOTH x1AES/EBU x1, Coaxial x2, Toslink x1Digital Input Sample RateUSB operating at Sample Frequency (Fs) from 44.1 kHz to 384 kHz, 16 bit to 32 bit, DSD 64, 128, 256 and 512.BLUETOOTH Sample Frequency (Fs) 44.1 kHz, 16 bit.AES/EBU, Coaxial, Toslink operating at Sample Frequency (Fs) from 44.1 kHz to 192 kHz, 16 bit to 24 bitControlTrigger input 12VDC x1IR control x1CommunicationEthernet RJ45 full remote configuration interfaceWi-Fi 802.11 b/g/nPower InputConfigured at factory for either 110-120 or 220-240 VAC, 50-60 HzAC Power Requirements45 WattsFinishBlack powder coated matte chassis with silver or black aluminum faceplateWeight23.5 lbsDimensions3.75″ H x 17.25″ W x 16.25″ D

AUDIO (LPCM)

Frequency Range2 Hz – 22 kHz (44.1 kHz)Amplitude Linearity0.1 dB (20 Hz – 20 kHz)Phase Linearity3 degrees (20 Hz – 20 kHz)Dynamic Range121 dB (1 kHz)Signal-to-Noise Ratio113 dB (1 kHz)Channel Separation106 dB (1 kHz)Total Harmonic Distortion0.0004% (1 kHz)Audio Output Level2.0V RMS (220 Ω output impedance) for Volume at 0.0dB3.0V RMS (220 Ω output impedance) for Volume at +8.0dBBalanced XLR Output+/- 2.0V RMS (440 Ω output impedance) for Volume at 0.0dB+/- 3.0V RMS (440 Ω output impedance) for Volume at +8.0dB

NETWORK, USB, SD CARD PLAYBACK

Playback Format Supply.dsf, .dff (DSD64, 128, 256, 512), .aif, .aiff, .alac, .flac, .m4a, .mp4, .wav, .ape, .mp3, .aac, .wma, .ogg, .asfFrequency Range2 Hz – 100 kHzSignal System16, 20, 24, & 32 bit PCM and 1 bit DSDSampling Frequency44.1 kHz to 384 kHz PCM and 2.822MHz – 22.5792 MHz DSDDynamic Range123 dBDSD System ClockFrequency 22.5792 MHzSignal-to-Noise Ratio112 dBAudio Output Level2.0V RMS (220 Ω output impedance) for Volume at 0.0dB3.0V RMS (220 Ω output impedance) for Volume at +8.0dBBalanced XLR Output+/- 2.0V RMS (440 Ω output impedance) for Volume at 0.0dB+/- 3.0V RMS (440 Ω output impedance) for Volume at +8.0dB

SPDIF PLAYBACK; COAXIAL, TOSLINK, AES/EBU (lPCM)

Frequency Range2 Hz – 100 kHzSignal System16, 20, and 24 bitSampling Frequency44.1 kHz to 192 kHz PCMDynamic Range123 dBSystem ClockFrequency 22.5792 MHSignal-to-Noise Ratio112 dBAudio Output Levelb2.0V RMS (220 Ω output impedance) for Volume at 0.0dB3.0V RMS (220 Ω output impedance) for Volume at +8.0dBBalanced XLR Output+/- 2.0V RMS (440 Ω output impedance) for Volume at 0.0dB+/- 3.0V RMS (440 Ω output impedance) for Volume at +8.0dB
