Marantz MODEL 30 Sound Master Tuned Integrated Amplifier
Marantz MODEL 30 Sound Master Tuned Integrated Amplifier
Load image into Gallery viewer, Marantz MODEL 30 Sound Master Tuned Integrated Amplifier
Load image into Gallery viewer, Marantz MODEL 30 Sound Master Tuned Integrated Amplifier

Marantz MODEL 30 Sound Master Tuned Integrated Amplifier

Marantz
$4,300.00
$4,300.00
Sale Call To Order
/
This is a pre order item. We will ship it when it comes in stock.
  • Model: MODEL 30
  • Type: Integrated Stereo Amplifier
  • Power Output: 100W + 100W (8Ω), 200W + 200W (4Ω)
  • Channels: 2.2
  • Custom Technology: HDAM (Hyper-Dynamic Amplifier Module)
  • Total Harmonic Distortion: 0.005% (1kHz, 8Ω)
  • Damping Factor: 500
  • Frequency Response: 5Hz - 50kHz
  • Input Sensitivity:
    - Phono Input MM: 2.3 mV / 39 kΩ
    - Phono Input MC: 250 µV
    - CD/Line/Recorder: 220 mV / 13 kΩ
    - Power Amplifier Input: 1.1 V / 13 kΩ
  • Signal-to-Noise Ratio:
    - PHONO (MM): 88dB
    - PHONO (MC): 75dB
    - CD: 107dB
  • Inputs: 6 Audio Inputs (PHONO/MM&MC/CD/TUNER/LINE 1/LINE 2) + 1 Recorder Input + 1 Power Amplifier Input
  • Outputs: Pre-out, 1 REC Out
  • Power Consumption: 130W
  • Standby Power Consumption: 0.2W
  • Dimensions (W x H x D): 443 x 130 x 432 mm
  • Weight: Net weight 14.8 kg; Gross weight 17.6 kg
  • Construction: SECC chassis, aluminum front panel, steel top cover
  • Included Features: Remote Control Bus Terminal, System Remote Controller, OLED UI Display
  • Phono Stage: Yes (MM & MC)
  • Chassis Material: Aluminum and Steel
  • Additional Technologies: Toroidal Transformer, SPK 100+ HDAM SA3 Current Feedback Amplifier
Specifications
  • Model: MODEL 30
  • Type: Integrated Stereo Amplifier
  • Power Output: 100W + 100W (8Ω), 200W + 200W (4Ω)
  • Channels: 2.2
  • Custom Technology: HDAM (Hyper-Dynamic Amplifier Module)
  • Total Harmonic Distortion: 0.005% (1kHz, 8Ω)
  • Damping Factor: 500
  • Frequency Response: 5Hz - 50kHz
  • Input Sensitivity:
    - Phono Input MM: 2.3 mV / 39 kΩ
    - Phono Input MC: 250 µV
    - CD/Line/Recorder: 220 mV / 13 kΩ
    - Power Amplifier Input: 1.1 V / 13 kΩ
  • Signal-to-Noise Ratio:
    - PHONO (MM): 88dB
    - PHONO (MC): 75dB
    - CD: 107dB
  • Inputs: 6 Audio Inputs (PHONO/MM&MC/CD/TUNER/LINE 1/LINE 2) + 1 Recorder Input + 1 Power Amplifier Input
  • Outputs: Pre-out, 1 REC Out
  • Power Consumption: 130W
  • Standby Power Consumption: 0.2W
  • Dimensions (W x H x D): 443 x 130 x 432 mm
  • Weight: Net weight 14.8 kg; Gross weight 17.6 kg
  • Construction: SECC chassis, aluminum front panel, steel top cover
  • Included Features: Remote Control Bus Terminal, System Remote Controller, OLED UI Display
  • Phono Stage: Yes (MM & MC)
  • Chassis Material: Aluminum and Steel
  • Additional Technologies: Toroidal Transformer, SPK 100+ HDAM SA3 Current Feedback Amplifier
