Details
Specifications
An amplifier that we unhesitatingly recommend for even the most demanding high-end system. This power amplifier is a compact version of our more powerful GFA-575se, yet it sacrifices nothing when it comes to revelation of nuance and inner detail. The GFA-565se is a powerhouse, housing 250W into 8 ohms. GFA-565se’s full power output is delivered into any loudspeaker load – unconditionally. The GFA-565se high current power amplifier goes beyond delivering top-notch sound – it's all about giving you exceptional quality and value for your investment. Our engineers are passionate about continuously innovating and improving the performance and features of our components. That is why our products gets rated as good as, if not better than, those way pricier options. Our engineering team is constantly striving to develop and design products that impress and surpassing even your highest expectations. At ADCOM, our aim is to make our products more accessible to a larger audience to savor that high-end audio goodness without the premium price tag.
Output Power
250 watts into 8 ohms
350 watts into 4 ohms
700 watts into 8 ohms, bridged
Frequency Resp.
Power Bandwidth (-3dB):
Input Impedance
100,000 ohms.
Input Sensitivity
Damping Factor
>800, 20Hz to 20kHz
Max Dimensions
7-1/4” x 17” x 14-3/16”
185mm x 432mm x 360mm
Weight
51lbs.(23kg)
Shipping Weight: 55lbs.(25kg)
The GFA-565se high power amplifier is capable of effortlessly driving a wide variety of loudspeakers, even those with exceptionally low impedances. It excels in maintaining high-power output consistently, even when faced with reactive impedances. Meticulous attention was given to ensure that the amplifier’s distortion remains minimal, especially when dealing with these complex loads, where the phase differences between voltage and current are significant.
The GFA-565se incorporates an impressively robust power supply, featuring a generously sized transformer that powers a reservoir of 72,000uF filter capacitance. This setup ensures a substantial reserve of power capability. The transformer itself was purposefully engineered to provide exceptional regulation, guaranteeing unwavering voltages regardless of the amplifier’s power requirements.
Notably, the GFA-565 possesses the ability to amplify DC signals and is unrestricted in its capacity to deliver energy across low-frequency and peak-bass ranges. Its gold-plated brass RCA input jacks with Teflon insulators exemplify the amplifier’s commitment to high quality.
Additionally,the high power audio amplifier features a front-panel LED indicator alerts users to thermal overload conditions, enhancing the amplifier’s safety features.
An amplifier that we unhesitatingly recommend for even the most demanding high-end system. This power amplifier is a compact version of our more powerful GFA-575se, yet it sacrifices nothing when it comes to revelation of nuance and inner detail. The GFA-565se is a powerhouse, housing 250W into 8 ohms. GFA-565se’s full power output is delivered into any loudspeaker load – unconditionally. The GFA-565se high current power amplifier goes beyond delivering top-notch sound – it's all about giving you exceptional quality and value for your investment. Our engineers are passionate about continuously innovating and improving the performance and features of our components. That is why our products gets rated as good as, if not better than, those way pricier options. Our engineering team is constantly striving to develop and design products that impress and surpassing even your highest expectations. At ADCOM, our aim is to make our products more accessible to a larger audience to savor that high-end audio goodness without the premium price tag.
Output Power
250 watts into 8 ohms
350 watts into 4 ohms
700 watts into 8 ohms, bridged
Frequency Resp.
Power Bandwidth (-3dB):
Input Impedance
100,000 ohms.
Input Sensitivity
Damping Factor
>800, 20Hz to 20kHz
Max Dimensions
7-1/4” x 17” x 14-3/16”
185mm x 432mm x 360mm
Weight
51lbs.(23kg)
Shipping Weight: 55lbs.(25kg)
The GFA-565se high power amplifier is capable of effortlessly driving a wide variety of loudspeakers, even those with exceptionally low impedances. It excels in maintaining high-power output consistently, even when faced with reactive impedances. Meticulous attention was given to ensure that the amplifier’s distortion remains minimal, especially when dealing with these complex loads, where the phase differences between voltage and current are significant.
The GFA-565se incorporates an impressively robust power supply, featuring a generously sized transformer that powers a reservoir of 72,000uF filter capacitance. This setup ensures a substantial reserve of power capability. The transformer itself was purposefully engineered to provide exceptional regulation, guaranteeing unwavering voltages regardless of the amplifier’s power requirements.
Notably, the GFA-565 possesses the ability to amplify DC signals and is unrestricted in its capacity to deliver energy across low-frequency and peak-bass ranges. Its gold-plated brass RCA input jacks with Teflon insulators exemplify the amplifier’s commitment to high quality.
Additionally,the high power audio amplifier features a front-panel LED indicator alerts users to thermal overload conditions, enhancing the amplifier’s safety features.
