This high-performance, medium-sized Tier 3 in-wall loudspeaker is a three-way model featuring two RDT III bass drivers, a C-CAM mid-range driver and MPD II transducer. It has a cut-out dimension of 527 x 198 mm and revolutionary patented Quik-Link speaker cable connector and Tri-Grip II for quick, simple, reliable and strong installation and fitting.
This high-performance, large Tier 3 in-wall loudspeaker is designed to deliver pristine, engaging acoustics where pristine sound quality is desired. It is a three-way model based on the Platinum Series 3G, and features the very latest acoustic technologies from Monitor Audio. This includes an MPD II high-frequency transducer, developed for the THX Certified Ultra Cinergy range. The precision specification of the Micro Pleated Diaphragm technology is designed to produce accurate, lifelike sound without any distortion. This is coupled with a C-CAM midrange driver and two RDT III bass drivers.
This combination ensures levels of acoustic transparency and detail found in Monitor Audio’s premium loudspeaker ranges, where much of his acoustic technology was developed. This really is the last word in installed performance.
It has a cut out dimension of 527 x 198 mm and uses the patented Quik-Link speaker cable connecter, which revolutionises the ease and speed of speaker installation. Tri-Grip has also been evolved for simple, reliable and strong fitment.
SpecificationsSystem Format3–WayNominal Impedance6 ohmMaximum Peak SPL* (single speaker @ 1m Z-Weighted)122 dBDrive Unit Complement2 x 5" (127 mm) RDT III bass driver, 1 x 3" (76 mm) C-CAM midrange driver, 1 x MPD II transducerCutout L x W527 x 198 mm (203/4 x 713/16")Pre-Construction BracketWM-BCorner SwitchOn/OffChannels1Minimum Impedance (20Hz to 20kHz)4.8 Ohm @ 150 HzContinuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor)150 WCrossover FrequencyLF/HF: 650 kHz MF/HF: 3.5 kHzExternal Dimensions (Including Grille (H x W x D))560 x 231 x 90 mm (221/16 x 91/8 x 39/16")Cabinet FinishMatt black & Orange & GreenMF Switch- /0/ +Frequency Response, Installed (-6dB)45 Hz – 60 kHzSensitivity (2.83Vrms@1m, Installed)88 dBRecommended Amplifier Power (RMS into 8 OHM, Music Signal)60 – 225 WMounting Depth85 mm (33/8")Weight (each)4.7 kg (10 lb 6 oz)Sold AsSingle UnitHF Switch- /0/ +
This high-performance, medium-sized Tier 3 in-wall loudspeaker is a three-way model featuring two RDT III bass drivers, a C-CAM mid-range driver and MPD II transducer. It has a cut-out dimension of 527 x 198 mm and revolutionary patented Quik-Link speaker cable connector and Tri-Grip II for quick, simple, reliable and strong installation and fitting.
This high-performance, large Tier 3 in-wall loudspeaker is designed to deliver pristine, engaging acoustics where pristine sound quality is desired. It is a three-way model based on the Platinum Series 3G, and features the very latest acoustic technologies from Monitor Audio. This includes an MPD II high-frequency transducer, developed for the THX Certified Ultra Cinergy range. The precision specification of the Micro Pleated Diaphragm technology is designed to produce accurate, lifelike sound without any distortion. This is coupled with a C-CAM midrange driver and two RDT III bass drivers.
This combination ensures levels of acoustic transparency and detail found in Monitor Audio’s premium loudspeaker ranges, where much of his acoustic technology was developed. This really is the last word in installed performance.
It has a cut out dimension of 527 x 198 mm and uses the patented Quik-Link speaker cable connecter, which revolutionises the ease and speed of speaker installation. Tri-Grip has also been evolved for simple, reliable and strong fitment.
SpecificationsSystem Format3–WayNominal Impedance6 ohmMaximum Peak SPL* (single speaker @ 1m Z-Weighted)122 dBDrive Unit Complement2 x 5" (127 mm) RDT III bass driver, 1 x 3" (76 mm) C-CAM midrange driver, 1 x MPD II transducerCutout L x W527 x 198 mm (203/4 x 713/16")Pre-Construction BracketWM-BCorner SwitchOn/OffChannels1Minimum Impedance (20Hz to 20kHz)4.8 Ohm @ 150 HzContinuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor)150 WCrossover FrequencyLF/HF: 650 kHz MF/HF: 3.5 kHzExternal Dimensions (Including Grille (H x W x D))560 x 231 x 90 mm (221/16 x 91/8 x 39/16")Cabinet FinishMatt black & Orange & GreenMF Switch- /0/ +Frequency Response, Installed (-6dB)45 Hz – 60 kHzSensitivity (2.83Vrms@1m, Installed)88 dBRecommended Amplifier Power (RMS into 8 OHM, Music Signal)60 – 225 WMounting Depth85 mm (33/8")Weight (each)4.7 kg (10 lb 6 oz)Sold AsSingle UnitHF Switch- /0/ +
