This medium-sized Tier 2 in-wall loudspeaker is a three-way model featuring two RST II bass drivers, an RST II mid-range driver and a C-CAM tweeter. It has a cut-out dimension of 527 x 198 mm and revolutionary patented Quik-Link speaker cable connector and Tri-Grip II for quick, simple, reliable and strong installation and fitting.
This medium-sized Tier 2 in-wall loudspeaker is designed to deliver pristine, engaging acoustics where high-performance sound is a key requirement. It is a three-way model featuring two RST II bass drivers, an RST II mid-range driver and a C-CAM tweeter. This combination clear and lifelike high-fidelity sound – of the quality you’d expect from any Monitor Audio passive box loudspeaker. It has a cut-out dimension of 527 x 198 mm and uses the patented Quik-Link speaker cable connecter, which revolutionises the ease and speed of speaker installation. Tri-Grip has also been evolved for simple, reliable and strong fitment.
Specifications
System Format3–WayNominal Impedance6 ohmMaximum Peak SPL* (single speaker @ 1m Z-Weighted)116 dBDrive Unit Complement2 x 5" (127 mm) RST II bass driver, 1 x 3" (76 mm) RST II midrange driver, 1 x 1" (25 mm) C-CAM tweeterCutout L x W527 x 198 mm (203/4 x 713/16")Pre-Construction BracketWM-BCorner SwitchOn/OffChannels1Minimum Impedance (20Hz to 20kHz)4.8 Ohm @ 1 kHz, (4.1 Ohm @ 15 kHz)Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor)120 WCrossover FrequencyLF/HF: 650 kHz, MF/HF: 3 kHzExternal Dimensions (Including Grille (H x W x D))560 x 231 x 90 mm (221/16 x 91/8 x 39/16")Cabinet FinishMatt black & Orange & BronzeHF Switch- /0/ +Frequency Response, Installed (-6dB)40 Hz – 35 kHzSensitivity (2.83Vrms@1m, Installed)87 dBRecommended Amplifier Power (RMS into 8 OHM, Music Signal)45 – 180 WMounting Depth85 mm (33/8")Weight (each)3.9 kg (8 lb 9 oz)Sold AsSingle Unit
This medium-sized Tier 2 in-wall loudspeaker is a three-way model featuring two RST II bass drivers, an RST II mid-range driver and a C-CAM tweeter. It has a cut-out dimension of 527 x 198 mm and revolutionary patented Quik-Link speaker cable connector and Tri-Grip II for quick, simple, reliable and strong installation and fitting.
This medium-sized Tier 2 in-wall loudspeaker is designed to deliver pristine, engaging acoustics where high-performance sound is a key requirement. It is a three-way model featuring two RST II bass drivers, an RST II mid-range driver and a C-CAM tweeter. This combination clear and lifelike high-fidelity sound – of the quality you’d expect from any Monitor Audio passive box loudspeaker. It has a cut-out dimension of 527 x 198 mm and uses the patented Quik-Link speaker cable connecter, which revolutionises the ease and speed of speaker installation. Tri-Grip has also been evolved for simple, reliable and strong fitment.
Specifications
System Format3–WayNominal Impedance6 ohmMaximum Peak SPL* (single speaker @ 1m Z-Weighted)116 dBDrive Unit Complement2 x 5" (127 mm) RST II bass driver, 1 x 3" (76 mm) RST II midrange driver, 1 x 1" (25 mm) C-CAM tweeterCutout L x W527 x 198 mm (203/4 x 713/16")Pre-Construction BracketWM-BCorner SwitchOn/OffChannels1Minimum Impedance (20Hz to 20kHz)4.8 Ohm @ 1 kHz, (4.1 Ohm @ 15 kHz)Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor)120 WCrossover FrequencyLF/HF: 650 kHz, MF/HF: 3 kHzExternal Dimensions (Including Grille (H x W x D))560 x 231 x 90 mm (221/16 x 91/8 x 39/16")Cabinet FinishMatt black & Orange & BronzeHF Switch- /0/ +Frequency Response, Installed (-6dB)40 Hz – 35 kHzSensitivity (2.83Vrms@1m, Installed)87 dBRecommended Amplifier Power (RMS into 8 OHM, Music Signal)45 – 180 WMounting Depth85 mm (33/8")Weight (each)3.9 kg (8 lb 9 oz)Sold AsSingle Unit
