This small Tier 2 in-ceiling loudspeaker is a two-way model featuring an RST II mid-bass driver and C-CAM tweeter. It has a cut out dimension of 171 mm and revolutionary patented Quik-Link speaker cable connector and Tri-Grip II for quick, simple, reliable and strong installation and fitting.
This small Tier 2 in-ceiling loudspeaker is designed to deliver pristine, engaging acoustics where high-performance sound is a key requirement. It is a two-way model featuring an RST II mid-bass driver and C-CAM tweeter. The performance benefit of having both within a single design means greatly improved clarity, wider dispersion into the listening environment, and clear lifelike high-fidelity sound – of the quality you’d expect from any Monitor Audio passive box loudspeaker. It has a cut-out dimension of 171 mm and uses the patented Quik-Link speaker cable connecter, which revolutionises the ease and speed of speaker installation. Tri-Grip has also been evolved for simple, reliable and strong fitment.
Specifications
System Format2–WayNominal Impedance8 ohmMaximum Peak SPL* (single speaker @ 1m Z-Weighted)111 dBDrive Unit Complement1 x 5" (127 mm) RST II mid-bass driver, 1 x 1 (25 mm) C-CAM tweeterCut-Out Hole Diameter171 mm (63/4")Pre-Construction BracketCS-BCorner SwitchOn/OffChannels1Minimum Impedance (20Hz to 20kHz)6.8 Ohm @ 150 HzContinuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor)65 WCrossover FrequencyLF/HF: 2.5 kHzExternal Dimensions (Including Grille (H x W x D))201 x 201 x 103 mm (715/16 x 715/16 x 44/16")Cabinet FinishMatt black & Orange & BronzeHF Switch- /0/ +Frequency Response, Installed (-6dB)40 Hz – 30 kHzSensitivity (2.83Vrms@1m, Installed)84 dBRecommended Amplifier Power (RMS into 8 OHM, Music Signal)35 – 130 WMounting Depth99 mm (37/8")Weight (each)1.5 kg (3 lb 5 oz)Sold AsSingle UnitSystem Format2–WayNominal Impedance8 ohmMaximum Peak SPL* (single speaker @ 1m Z-Weighted)111 dBDrive Unit Complement1 x 5" (127 mm) RST II mid-bass driver, 1 x 1 (25 mm) C-CAM tweeterCut-Out Hole Diameter171 mm (63/4")Pre-Construction BracketCS-BCorner SwitchOn/OffChannels1Minimum Impedance (20Hz to 20kHz)6.8 Ohm @ 150 HzContinuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor)65 WCrossover FrequencyLF/HF: 2.5 kHzExternal Dimensions (Including Grille (H x W x D))201 x 201 x 103 mm (715/16 x 715/16 x 44/16")Cabinet FinishMatt black & Orange & BronzeHF Switch- /0/ +Frequency Response, Installed (-6dB)40 Hz – 30 kHzSensitivity (2.83Vrms@1m, Installed)84 dBRecommended Amplifier Power (RMS into 8 OHM, Music Signal)35 – 130 WMounting Depth99 mm (37/8")Weight (each)1.5 kg (3 lb 5 oz)Sold AsSingle Unit
This small Tier 2 in-ceiling loudspeaker is a two-way model featuring an RST II mid-bass driver and C-CAM tweeter. It has a cut out dimension of 171 mm and revolutionary patented Quik-Link speaker cable connector and Tri-Grip II for quick, simple, reliable and strong installation and fitting.
This small Tier 2 in-ceiling loudspeaker is designed to deliver pristine, engaging acoustics where high-performance sound is a key requirement. It is a two-way model featuring an RST II mid-bass driver and C-CAM tweeter. The performance benefit of having both within a single design means greatly improved clarity, wider dispersion into the listening environment, and clear lifelike high-fidelity sound – of the quality you’d expect from any Monitor Audio passive box loudspeaker. It has a cut-out dimension of 171 mm and uses the patented Quik-Link speaker cable connecter, which revolutionises the ease and speed of speaker installation. Tri-Grip has also been evolved for simple, reliable and strong fitment.
Specifications
System Format2–WayNominal Impedance8 ohmMaximum Peak SPL* (single speaker @ 1m Z-Weighted)111 dBDrive Unit Complement1 x 5" (127 mm) RST II mid-bass driver, 1 x 1 (25 mm) C-CAM tweeterCut-Out Hole Diameter171 mm (63/4")Pre-Construction BracketCS-BCorner SwitchOn/OffChannels1Minimum Impedance (20Hz to 20kHz)6.8 Ohm @ 150 HzContinuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor)65 WCrossover FrequencyLF/HF: 2.5 kHzExternal Dimensions (Including Grille (H x W x D))201 x 201 x 103 mm (715/16 x 715/16 x 44/16")Cabinet FinishMatt black & Orange & BronzeHF Switch- /0/ +Frequency Response, Installed (-6dB)40 Hz – 30 kHzSensitivity (2.83Vrms@1m, Installed)84 dBRecommended Amplifier Power (RMS into 8 OHM, Music Signal)35 – 130 WMounting Depth99 mm (37/8")Weight (each)1.5 kg (3 lb 5 oz)Sold AsSingle UnitSystem Format2–WayNominal Impedance8 ohmMaximum Peak SPL* (single speaker @ 1m Z-Weighted)111 dBDrive Unit Complement1 x 5" (127 mm) RST II mid-bass driver, 1 x 1 (25 mm) C-CAM tweeterCut-Out Hole Diameter171 mm (63/4")Pre-Construction BracketCS-BCorner SwitchOn/OffChannels1Minimum Impedance (20Hz to 20kHz)6.8 Ohm @ 150 HzContinuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor)65 WCrossover FrequencyLF/HF: 2.5 kHzExternal Dimensions (Including Grille (H x W x D))201 x 201 x 103 mm (715/16 x 715/16 x 44/16")Cabinet FinishMatt black & Orange & BronzeHF Switch- /0/ +Frequency Response, Installed (-6dB)40 Hz – 30 kHzSensitivity (2.83Vrms@1m, Installed)84 dBRecommended Amplifier Power (RMS into 8 OHM, Music Signal)35 – 130 WMounting Depth99 mm (37/8")Weight (each)1.5 kg (3 lb 5 oz)Sold AsSingle Unit
