This medium-sized Tier 2 in-ceiling loudspeaker is a two-way model featuring an RST II mid-bass driverand C-CAM tweeter. It has a cut out dimension of 212 mm and revolutionary patented Quik-Link speaker cable connector and Tri-Grip II for quick, simple, reliable and strong installation and fitting.
This medium-sized Tier 2 in-ceiling loudspeaker is designed to deliver pristine, engaging acoustics where high-performance sound is a key requirement. It is a two-way model featuring an RST II mid-bass driver and C-CAM tweeter. The performance benefit of having both within a single design means greatly improved clarity, wider dispersion into the listening environment, and clear lifelike high-fidelity sound – of the quality you’d expect from any Monitor Audio passive box loudspeaker. It has a cut-out dimension of 212 mm and uses the patented Quik-Link speaker cable connecter, which revolutionises the ease and speed of speaker installation. Tri-Grip has also been evolved for simple, reliable and strong fitment.
Specification
sSystem Format2–WayNominal Impedance8 ohmMaximum Peak SPL* (single speaker @ 1m Z-Weighted)114 dBDrive Unit Complement1 x 7" (178 mm) RST II mid-bass driver, 1 x 1" x (25 mm) C-CAM tweeterCut-Out Hole Diameter212 mm (83/8")Pre-Construction BracketCM-BCorner SwitchOn/OffChannels1Minimum Impedance (20Hz to 20kHz)6.6 Ohm @ 150 HzContinuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor)75 WCrossover FrequencyLF/HF: 2.25 kHzExternal Dimensions (Including Grille (H x W x D))242 x 242 x 103 mm (91/2 x 91/2 x 44/16")Cabinet FinishMatt black & Orange & BronzeHF Switch- /0/ +Frequency Response, Installed (-6dB)35 Hz – 35 kHzSensitivity (2.83Vrms@1m, Installed)86 dBRecommended Amplifier Power (RMS into 8 OHM, Music Signal)40 – 150 WMounting Depth99 mm (37/8")Weight (each)2 kg (4 lb 6 oz)Sold AsSingle Unit
This medium-sized Tier 2 in-ceiling loudspeaker is a two-way model featuring an RST II mid-bass driverand C-CAM tweeter. It has a cut out dimension of 212 mm and revolutionary patented Quik-Link speaker cable connector and Tri-Grip II for quick, simple, reliable and strong installation and fitting.
This medium-sized Tier 2 in-ceiling loudspeaker is designed to deliver pristine, engaging acoustics where high-performance sound is a key requirement. It is a two-way model featuring an RST II mid-bass driver and C-CAM tweeter. The performance benefit of having both within a single design means greatly improved clarity, wider dispersion into the listening environment, and clear lifelike high-fidelity sound – of the quality you’d expect from any Monitor Audio passive box loudspeaker. It has a cut-out dimension of 212 mm and uses the patented Quik-Link speaker cable connecter, which revolutionises the ease and speed of speaker installation. Tri-Grip has also been evolved for simple, reliable and strong fitment.
Specification
sSystem Format2–WayNominal Impedance8 ohmMaximum Peak SPL* (single speaker @ 1m Z-Weighted)114 dBDrive Unit Complement1 x 7" (178 mm) RST II mid-bass driver, 1 x 1" x (25 mm) C-CAM tweeterCut-Out Hole Diameter212 mm (83/8")Pre-Construction BracketCM-BCorner SwitchOn/OffChannels1Minimum Impedance (20Hz to 20kHz)6.6 Ohm @ 150 HzContinuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor)75 WCrossover FrequencyLF/HF: 2.25 kHzExternal Dimensions (Including Grille (H x W x D))242 x 242 x 103 mm (91/2 x 91/2 x 44/16")Cabinet FinishMatt black & Orange & BronzeHF Switch- /0/ +Frequency Response, Installed (-6dB)35 Hz – 35 kHzSensitivity (2.83Vrms@1m, Installed)86 dBRecommended Amplifier Power (RMS into 8 OHM, Music Signal)40 – 150 WMounting Depth99 mm (37/8")Weight (each)2 kg (4 lb 6 oz)Sold AsSingle Unit
