Details
Specifications
The Power T1000-1bdCP is a 1,000 Watt mono amplifier featuring Constant Power delivering up to 25% more power across all impedance loads. The frequency response of the T1000-1bdCP is optimized exclusively for use with subwoofers.
The new Constant Power amplifiers are the most powerful amplifiers on the market PERIOD! The T1000-1bdCP is based on the legendary T1000-1bd amplifier design with a proprietary "Constant Power" configuration delivering up to 25% more power (Watts) across all impedance loads. The listening experience is cleaner, louder and more impressive than ever before. The T1000-1bdCP, pumps out a heart-stopping Kilowatt, enough power for any reasonably sane subwoofer system.
Number of Channels1Total Power(Sum of Rated Power)1000 Watts RMSRated Power(RMS Continuous Power)700 Watts x 1 @ 4-Ohm1000 Watts x 1 @ 2-Ohm1000 Watts x 1 @ 1-OhmDynamic Power(PVC/PowerCube®)772 Watts x 1 @ 4-Ohms1299 Watts x 1 @ 2-Ohms1395 Watts x 1 @ 1-OhmBridgeableNoFrequency Response20Hz to 250Hz +/-0.5dBInput Sensitivity150 mV to 4 VCircuit Topology ClassClass BDEfficiency(average)85.6% @ 4-Ohm82.1% @ 2-Ohm70% @ 1-OhmTotal Harmonic Distortion(THD+Noise)4-Ohm:<1.0%2-Ohm:<1.0%1-Ohm:<1.0%Signal Input1 RCA pairSignal Output1 RCA pairTone ControlsBass: 0dB to +18dB @ 45HzCrossover ControlsLow-Pass (LP): 35Hz-250Hz @ 24dB/octave ButterworthInfrasonic: 12dB/octave Butterworth, -3dB @ 28HzRemote ControlsOptional Remote PEQ(overrides built-in Punch Bass)Visual IndicatorsPower (Blue LED)Thermal (Red LED)Protect (Yellow LED)Power Wire Gauge4 AWGPower Input ConnectorBlockSpeaker Wire Gauge8 AWG to 18 AWGSpeaker Output ConnectorBlockCoolingConvectionHeatsinkOperating Voltage9 - 16 VDCRecommended Fuse(not included)150 AAverage Current Draw(13.8V Music)70 AMax. Current Draw(13.8V Sinewave)140 ASuggested Alternator100 AIncluded In The Box
Dimensions(H x W x D)2.14 x 8.14 x 13.66 (in)5.44 x 20.68 x 34.69 (cm)Shipping Weight12.2 Lbs. (5.53 Kg.)
The Power T1000-1bdCP is a 1,000 Watt mono amplifier featuring Constant Power delivering up to 25% more power across all impedance loads. The frequency response of the T1000-1bdCP is optimized exclusively for use with subwoofers.
The new Constant Power amplifiers are the most powerful amplifiers on the market PERIOD! The T1000-1bdCP is based on the legendary T1000-1bd amplifier design with a proprietary "Constant Power" configuration delivering up to 25% more power (Watts) across all impedance loads. The listening experience is cleaner, louder and more impressive than ever before. The T1000-1bdCP, pumps out a heart-stopping Kilowatt, enough power for any reasonably sane subwoofer system.
Number of Channels1Total Power(Sum of Rated Power)1000 Watts RMSRated Power(RMS Continuous Power)700 Watts x 1 @ 4-Ohm1000 Watts x 1 @ 2-Ohm1000 Watts x 1 @ 1-OhmDynamic Power(PVC/PowerCube®)772 Watts x 1 @ 4-Ohms1299 Watts x 1 @ 2-Ohms1395 Watts x 1 @ 1-OhmBridgeableNoFrequency Response20Hz to 250Hz +/-0.5dBInput Sensitivity150 mV to 4 VCircuit Topology ClassClass BDEfficiency(average)85.6% @ 4-Ohm82.1% @ 2-Ohm70% @ 1-OhmTotal Harmonic Distortion(THD+Noise)4-Ohm:<1.0%2-Ohm:<1.0%1-Ohm:<1.0%Signal Input1 RCA pairSignal Output1 RCA pairTone ControlsBass: 0dB to +18dB @ 45HzCrossover ControlsLow-Pass (LP): 35Hz-250Hz @ 24dB/octave ButterworthInfrasonic: 12dB/octave Butterworth, -3dB @ 28HzRemote ControlsOptional Remote PEQ(overrides built-in Punch Bass)Visual IndicatorsPower (Blue LED)Thermal (Red LED)Protect (Yellow LED)Power Wire Gauge4 AWGPower Input ConnectorBlockSpeaker Wire Gauge8 AWG to 18 AWGSpeaker Output ConnectorBlockCoolingConvectionHeatsinkOperating Voltage9 - 16 VDCRecommended Fuse(not included)150 AAverage Current Draw(13.8V Music)70 AMax. Current Draw(13.8V Sinewave)140 ASuggested Alternator100 AIncluded In The Box
Dimensions(H x W x D)2.14 x 8.14 x 13.66 (in)5.44 x 20.68 x 34.69 (cm)Shipping Weight12.2 Lbs. (5.53 Kg.)
